Additional information
Weight | 105 g |
---|---|
Dimensions | 118,5 × 118,5 × 27,5 mm |
AC Current | 63 mA |
Base | None |
Beam Angle | 96° |
Body Material | PA – Polyamides |
Carton | 60 (pcs) |
Case | C12 |
Case Sub Type | W |
CE | Yes |
Color Temperature | 6500K |
Color Temperature Name | Cool White |
CRI | 85 Ra |
Declared Radiant Power | 2.46 W |
Diameter | 118.5 mm |
Diameter-Height-Width | D:118.5 mm H:27.5 mm W:118.5 mm |
Diffuser Material | PC – Polycarbonates |
Dimmable | No |
Driver Type | On Board IC |
EAC | Yes |
Efficiency Class | E (A-G) |
Efficiency Compared to LED | 44 % |
Equivalent CFL | 12 W |
Equivalent Incandescent | 60 W |
Equivalent LED Bulb | 10 W |
Euro Plate 1 | 27 (carton) |
Euro Plate 2 | 1620 (pcs) |
Fragile | Yes |
GTIN | 8684216001017 |
Height | 27.5 mm |
Hg Free Compliant | Yes |
IP Class | IP50 |
LED Chip Model | Samsung |
Life Expectancy | 15 Years |
Lighting Efficiency | 118 lm/W |
Luminous Flux | 763 lm |
Mains Frequency Maximum | 60 Hz |
Mains Frequency Minimum | 40 Hz |
Mains Voltage Rate Maximum | 240 Vac |
Mains Voltage Rate Minimum | 110 Vac |
Operating Temperature Min | -20° |
Operating Temperature Max | 60° |
Power Factor | 0.45 |
Product Code | DLRDC12W652801NN |
Power Tuled | 6.48 W |
Product Long Name | DLRDC12W652801NN Tuled Redeem Downlight C12W 6.5W 763lm 6500K Cool White |
Product Short Name | Tuled Redeem Downlight C12W 6500K |
Product Type | LED Downlight |
Protected against water | No |
Recyclable | No |
RoHs 2011/65/EU Compliant | Yes |
Safe to Touch | No |
Safe To Trash | No |
Series Name | Redeem |
Surface Temperature | 60℃ |
Switching Count Expectancy | 60000 On/Off |
Warranty | 36 Month |
Weight | 105 g/unit |
Width | 118.5 mm |
Yearly Consumption | 6.48 kWh/1000hours |
